Sensopart UMT 30-1300-A-IUD-L5

(0) 0 Reviews 0 Orders 0 Wish listed

26,334EGP

Quantity :

Total price :

(Tax : )

Overview
Reviews

🔷 SensoPart UMT 30-1300-A-IUD-L5 – Ultrasonic Distance Sensor, Analog + IO-Link, M12 Plug The SensoPart UMT 30-1300-A-IUD-L5 is a high-performance ultrasonic distance sensor designed for non-contact measurement up to 1300 mm. It features dual analog outputs (0–10 V and 4–20 mA) along with IO-Link interface for flexible integration into modern automation systems. Immune to surface color, material, or transparency, this sensor is ideal for applications involving level detection, object positioning, and automated distance control. Its rugged housing and M12 5-pin connector ensure stable operation in industrial environments. Description • Ultrasonic sensor with 1300 mm measuring range • Dual analog output: 0–10 V / 4–20 mA • IO-Link interface (v1.1) for digital communication • Reliable detection regardless of object color or material • M12 5-pin connector (L5) for easy installation • Ideal for fill level measurement, positioning, and distance control Product Data Specification Details Model UMT 30-1300-A-IUD-L5 Sensor Type Ultrasonic distance sensor Measuring Range 100–1300 mm Output Type Analog (0–10 V / 4–20 mA) + IO-Link Connector Type M12 5-pin connector (L5) Housing Type Compact rectangular industrial housing Operating Voltage 15–30 V DC Protection Rating IP67 Accuracy ±1% of range (typical) Ambient Temperature –25 °C to +60 °C Applications Fill level monitoring, distance measurement, object positioning
