Sensopart UMT 30-3400-A-IUD-L5

(0) 0 Reviews 0 Orders 0 Wish listed

27,902EGP

Quantity :

Total price :

(Tax : )

Overview
Reviews

🔷 SensoPart UMT 30-3400-A-IUD-L5 – Long-Range Ultrasonic Sensor, Analog + IO-Link, M12 Plug The SensoPart UMT 30-3400-A-IUD-L5 is a long-range ultrasonic distance sensor engineered for reliable non-contact object or level detection up to 3400 mm. It supports both analog output formats (0–10 V and 4–20 mA) and IO-Link digital communication, enabling flexible integration into smart automation systems. Immune to color, surface, and material type, it’s ideal for applications like large tank fill-level monitoring, bulk handling, and machine positioning in demanding industrial environments. Description • Ultrasonic sensor with extended measuring range up to 3400 mm • Analog output: 0–10 V / 4–20 mA + IO-Link (v1.1) • Non-contact detection unaffected by surface or material • Compact rectangular housing with rugged industrial design • M12 5-pin connector (L5) for fast and secure wiring • Ideal for level detection, bulk material control, and conveyor systems Product Data Specification Details Model UMT 30-3400-A-IUD-L5 Sensor Type Ultrasonic distance sensor Measuring Range 350–3400 mm Output Type Analog (0–10 V / 4–20 mA) + IO-Link Connector Type M12 5-pin connector (L5) Housing Type Compact industrial rectangular housing Operating Voltage 15–30 V DC Protection Rating IP67 Accuracy ±1% of range (typical) Ambient Temperature –25 °C to +60 °C Applications Fill level control, long-distance detection, material handling
